linear weighing automatic packaging machine automatic Two Layers Belt Vibrate Linear Weigher for sugar cauliflower
Power:1200WModel Number:PG-AX1
| Lead Time | Quantity(Sets) | 1 - 1 | 2 - 10 | >10 |
| EstTime(days) | 25 | 45 | To be negotiated |
Shipping:Support Sea freight
Service:2 years for machinery warranty | 2 years for Core Components
Quick Details
Type:Multi-Function Packaging Machine
Applicable Industries:Manufacturing Plant, Food & Beverage Factory, Food & Beverage Shops, Other
Weight (KG):200
Showroom Location:None
Condition:New
Function:FILLING, Sealing
Application:Food, Commodity, Medical, Chemical, Machinery & Hardware, Tobacco
Packaging Type:Stand-up Pouch, Bags, Belt
Packaging Material:Plastic, Wood
Automatic Grade:Automatic
Driven Type:Electric
Voltage:220V
Place of Origin:Guangdong, China
Brand Name:PACCURA
Dimension(L*W*H):1200(L)x660(W)x1050(H)mm
Warranty:2 years
Key Selling Points:Easy to Operate
Marketing Type:New Product 2020
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Warranty of core components:2 years
Core Components:Motor, PLC, Other
Production Capacity:10bag/min
Product name:Two Layers Belt Vibrate Linear Weigher
Packing speed:10P/M
Weighing Range:50~1000g
Hopper Volume:4.5L
Control Panel:7" Touch Screen
Power Requirement:220V / 1200W / 50/60Hz / 6A
Packing Dimension (mm):1200(L)x660(W)x1050(H)
Options:Timing Hopper/Printer/Reject Device
Gross Weight:110kg
After-sales Service Provided:Online support
Features
1.Brand new highly integrated modular control system.
2.Customize special sensors to ensure weighing accuracy.
3.Adopting double-layer feeding structure, upper belt feeding, lower vibrating plate feeding, it is convenient to control the thickness of the line vibrating plate material to ensure accurate feeding.
4.The stepless feeding mode is adopted to control the flow of materials in real time to ensure the accuracy of weighing.
5.Easy to disassemble structure design, easy to maintain and clean.
6.During operation, the parameter settings can be modified according to the actual production conditions, and the operation is
simple.
Mechanical Character
1.The whole machine is made of stainless steel food-grade materials to ensure food hygiene and safety.
2.Customized food-grade conveyor belt to meet different application requirements of different materials.
3.Double-vibration plate is used for blanking, the main vibration plate is quickly fed, and the auxiliary vibration plate is accurately refilled to ensure the feeding accuracy.
6.The main and auxiliary vibration plates are equipped with independent gates, which automatically realize the opening and closing actions of the gates according to the signal feedback.
7.Parts in contact with materials can be quickly disassembled, making cleaning more convenient.
| Model | PG-AX1 |
| Identify Code | XM1-2-2 |
| Weighing Range | 500-12000g |
| Accuracy | X(1) |
| Max Speed | 8P/M |
| Hopper Volume | 15L |
| Parameters Press No. | 100 |
| Max Products Mixed | 1 |
| Control Panel | 7”Touch Screen |
| Options | Dimple Plate/Timing Hopper/Printer/Reject Device |
| Power Requirement | 220V/250W/50/60Hz/1.2A |
| Packing Dimension(mm) | 1150(L)x700(W)x1090(H) |
| Gross Weight | 200kg |
Application
Suitable for quantitative weighing of brown sugar, brown sugar, industrial salt, etc., which have poor fluidity and slight viscosity, as well as fresh corn kernels, cauliflower, onion slices and other block, diced, stems, and other vegetables and medicinal products.
